TECHNICAL SPECIFICATIONS | |||||||||||||||||||
Supply Voltage: | 220 V 50 Hz AC | ||||||||||||||||||
Auxiliary Voltage Supply: | |||||||||||||||||||
VOLTS AC | CURRENT AC | VOLTS DC | CURRENT DC | ||||||||||||||||
0 - 55 | 7 A | 0 - 77 | 3,5 A | ||||||||||||||||
0 - 110 | 3,5 A | 0 - 155 | 1,7 A | ||||||||||||||||
0 - 220 | 1,8 A | 0 - 311 | 0,9 A | ||||||||||||||||
0 - 500 | 0,8 A | ||||||||||||||||||
0 - 1000 | 0,4 A | ||||||||||||||||||
OUTPUT VOLTS |
RIPPLE Pk-Pk |
CURRENT | RIPPLE Pk-Pk |
CURRENT | |||||||||||||||
50 | 10% | 0,65 A | 5% | 290 mA | |||||||||||||||
110 | 5,9% | 1,0 A | 5% | 800 mA | |||||||||||||||
220 | 1,6% | 0,5 A | 1% | 250 mA | |||||||||||||||
Ammeter: | Ranges: 199,9 mA, 1,999 A and 19,99 A a.c or d.c Accuracy: 1 % of reading + 2 digits. Linearity: 0,05% Temperature coefficient: 30ppm/oC. Protection: 10 A continuous on any range. |
||||||||||||||||||
Voltmeter: | Range: 1200 V a.c or 400 volts d.c. Accuracy: 0,5% of reading + 2 digits. Linearity: 0,05% Temperature coefficient: 30ppm/oC. |
||||||||||||||||||
Resistors: |
|
||||||||||||||||||
Capacitor: | |
||||||||||||||||||
Enclosure: | |
||||||||||||||||||
Weight: | Approximately 26 Kg. | ||||||||||||||||||
Guarantee: | |
Since our policy is one of continued product improvement the manufacturer reserves
the right to supply products which may differ slightly from the above.
